Rockhaven Discovers Multiple New Mineralized Structures – Exploration Drilling Cuts 10.12 m grading 1.16 g/t Gold and 18.7 g/t Silver at Klaza Project, Yukon

December 4, 2017 - Rockhaven Resources Ltd. (TSX-V:RK) (“Rockhaven”) is pleased to announce the results for the remaining seven diamond drill holes and other exploration activities conducted during the reconnaissance phase of the 2017 program at its 100% owned Klaza gold-silver property, located in the Dawson Range Gold Belt of southern Yukon.

A total of 15,922 m in 96 holes were completed during the 2017 exploration program. Results in this release are from diamond drilling, excavator trenching, soil sampling and ground geophysical surveys that were designed to evaluate prospective areas of the Klaza property, which lie outside of the known mineral resource areas. The program successfully identified seven new mineralized zones and a number of geochemical and geophysical anomalies, which are priority targets for follow-up drilling in 2018.

Highlights from this news release include:

  • A series of new mineralized veins were discovered in a single drill fence completed north of the current resource area, returning 1.16 g/t gold and 18.7 g/t silver over 10.12 m, 12.60 g/t gold and 312 g/t silver over 0.46 m, 9.43 g/t gold and 180 g/t silver over 0.86 m, and 5.63 g/t gold and 91.4 g/t silver over 0.94 m;
  • Trenching and prospecting samples collected at the Victoria Target, southeast of the newly discovered veins, returned a chip sample grading 4.95 g/t gold and 135 g/t silver over 1.5 m and rock samples with peak values of 35.3 g/t gold and 1,145 g/t silver; and,
  • A new prospecting discovery at the Rusk Target, 5 km south of the current resource area, identified northwest trending linear structures where the peak value from rock sampling returned 2.82 g/t gold and 2,070 g/t silver.

“We are excited by the discovery of multiple mineralized structures north of the Klaza Zone and consider these structures high priority targets for diamond drilling in 2018.” stated Matt Turner, Rockhaven’s CEO. “These new structures are located within 500 m of the currently envisioned open pit and are similar in character to the known zones that host the current inferred resource of 1,360,000 gold ounces.”

Northern Drill Fence

A fence, comprising five diamond drill holes, was completed north of the Central Klaza Zone to test an area where no mechanized exploration had been completed previously. This drilling targeted a number of linear magnetic and electro-magnetic anomalies, similar to those marking known mineralized zones. The southern three holes intersected a series of semi-massive sulphide veins that are spatially associated with porphyry dykes. These veins and dykes closely resemble those within the inferred resource.

Exploration in 2018 will test these newly identified structures along strike to the northwest, within the Western Fault Block which hosts the high-grade Western BRX and Western Klaza zones, and to the southeast where soil sampling has identified strong gold-in-soil anomalies.

Significant drill results from the newly discovered vein zones are shown in Table I.

Table I – Significant Diamond Drill Intersections from Northern Drill Fence

Hole ID From (m) To (m) Int. (m)* Au (g/t) Ag (g/t) Pb (%) Zn (%)
KL-17-395 61.76 63.48 1.72 2.21 7.71 0.012 0.035
and 112.49 113.06 0.57 1.09 2.50 0.009 0.033
and 121.06 121.38 0.32 1.31 9.30 0.110 0.315
and 186.82 187.59 0.77 1.08 10.3 0.514 0.489
KL-17-403 57.95 60.04 2.09 1.81 109 0.050 1.502
and 174.59 184.71 10.12 1.16 18.7 0.084 0.184
including 174.59 175.35 0.76 6.91 80.2 0.139 1.065
including 184.14 184.71 0.57 6.75 75.1 0.341 0.131
and 231.03 231.49 0.46 12.60 312 1.350 0.663
and 245.36 246.22 0.86 9.43 180 1.400 1.250
and 275.65 276.93 1.28 1.08 46.6 0.564 0.387
and 302.83 303.77 0.94 5.63 91.4 1.806 3.926
and 312.06 312.46 0.40 1.13 15.2 0.037 0.055
KL-17-406 50.20 50.72 0.52 1.08 9.30 0.048 0.103
and 192.00 192.92 0.92 2.18 80.7 0.919 2.380
and 268.51 269.00 0.49 6.37 5.00 0.022 0.044

* Represents the diamond drill hole sample length. True widths are estimated to be approximately 80-90% of the interval.

Rex and Chevron/Dickson Zones

The Rex Zone was discovered in 2016, 1 km southeast of the Eastern BRX Zone (see news release dated September 8, 2016). In 2017, three additional holes were drilled down-dip and along strike of the discovery hole. The most significant intersections came from hole KL-17-434 located 75 m along strike to the northwest, as shown on Table II below. Additional work is required to confirm the orientation and character of the mineralization within the Rex Zone.

The Chevron and Dickson Zones are two of the eleven previously identified mineralized zones within the core of the Klaza property. Four holes were drilled into these lightly explored zones in 2017. The results from three of the four holes were previously released (see Rockhaven news release dated September 26, 2017). Significant intersections from the final hole (KL-17-390) are shown in Table II.

Table II – Significant Diamond Drill Intersections from Rex and Chevron/Dickson

Hole ID Zone From (m) To (m) Int. (m)* Au (g/t) Ag (g/t) Pb (%) Zn (%)
KL-17-390 Chevron 66.87 67.30 0.43 1.24 28.1 0.687 0.313
and Dickson 220.84 221.97 1.13 1.33 77.9 0.276 0.358
and Dickson 233.24 234.76 1.52 1.32 1.30 0.008 0.027
KL-17-432 REX 32.37 34.00 1.63 1.07 5.00 0.002 0.007
and REX 59.63 60.18 0.55 1.71 8.00 0.003 0.007
KL-17-434 REX 18.74 19.35 0.61 9.31 7.00 0.003 0.012
and REX 29.45 31.34 1.89 1.30 4.72 0.005 0.009
and REX 41.40 43.23 1.83 1.14 8.40 0.019 0.051

* Represents the diamond drill hole sample length. True widths are estimated to be approximately 80-90% of the interval.
Drill hole KL-17-433 did not return significant mineralization.

Encouraging results from recent surface exploration activities elsewhere on the 287 km2 Klaza property are described in the following paragraphs. None of these outside targets have been systematically trenched or drilled to date.

Victoria Target

Prospecting in late 2016 and early 2017 returned favourable results 3.2 km to the southeast of the area of the inferred resources. Two grab samples returned 35.30 g/t gold and 1,145 g/t silver, and 12.10 g/t gold and 2,360 g/t silver, respectively, from a broad recessive linear feature. An excavator trench across the linear intersected two mineralized intervals, which returned 5.43 g/t gold and 149 g/t silver over 1.0 m and 4.95 g/t gold and 134.75 g/t silver over 1.5 m. An additional rock sample collected on the eastern, untrenched flank of the linear yielded 7.81 g/t gold and 51.1 g/t silver, suggesting the potential for additional parallel veins.

Rusk Target

The Rusk Target, located 3.5 km south of the current inferred resource, features a gold, silver, antimony and arsenic soil geochemical anomaly that spans an area of over 2.6 km2. This target saw cursory exploration in the 1970s and 1980s and was acquired by Rockhaven in mid-2015. It was the focus of a contour soil sampling program in 2016, which produced the highest arsenic-in-soil anomaly (1,900 ppm) returned to date on the Klaza property. Follow-up work in 2017 included ground geophysics, prospecting and additional soil sampling.

A total of 36 rock samples were collected at the Rusk Target in 2017, the best of which yielded 2.82 g/t gold and 2,070 g/t silver. Ten of the 36 samples returned greater than 1.0 g/t gold and four returned greater than 1,000 g/t silver. The mineralized samples are spatially related to northwest-trending linear structures marked by magnetic lows and electro-magnetic conductors.

Val Target

The Val Target is located 2.5 km north of the historical Mount Nansen Mine and 6 km southeast of the area of the inferred resources on the Klaza property. It lies on the northern slope of Back Creek, one of the most productive placer gold creeks in the Mount Nansen Gold Camp. Previous work has outlined soil geochemical anomalies. Exploration activity in 2017 consisted of ground based geophysical surveys, which identified north-northwest trending linear magnetic lows and electro-magnetic conductors.


All analyses of core, rock and soil samples from the 2017 program were performed by ALS Minerals with sample preparation in North Vancouver, Whitehorse, Yellowknife or Thunder Bay and assays and geochemical analyses in North Vancouver. Samples were routinely analyzed for gold by fire assay followed by atomic absorption (Au-AA24) and 48 other elements by inductively coupled plasma-mass spectrometry (ME-MS61). Samples that exceeded the detection limits of the routine methods were assayed for silver, copper, lead and zinc by inductively coupled plasma-atomic emission spectroscopy (Ag/Cu/Pb/Zn - OG62) and gold by gravimetric analysis (Au-GRA22). Rigorous procedures were in place regarding sample collection, chain of custody and data entry. Certified assay standards, coarse reject duplicates, field duplicates and blanks were routinely inserted into the sample stream to ensure integrity of the assay process. All of the results reported have passed the QAQC screening.

Additional information about the Klaza property Mineral Resource and Preliminary Economic Assessment is summarized in Rockhaven’s March 1, 2016 technical report titled, “Technical Reports and PEA for the Klaza Au-Ag deposit, Yukon Canada for Rockhaven Resources Ltd.” which can be viewed at under the Rockhaven profile or on the Rockhaven website at

The 2017 program was managed by Archer, Cathro & Associates (1981) Limited (Archer Cathro). Technical information in this news release has been approved by Matthew R. Dumala, P.Eng., a geological engineer with Archer Cathro and qualified person for the purpose of National Instrument 43-101.

About Rockhaven

Rockhaven Resources Ltd. is a mineral exploration company focused on growth through the advancement of its Klaza project. For additional information concerning Rockhaven or its Klaza project please visit Rockhaven’s website at

Matthew Turner
President, CEO and Director
Rockhaven Resources Ltd.

Neither the TSX Venture Exchange nor its Regulation Services Provider (as that term is defined in the policies of the TSX Venture Exchange) accepts responsibility for the adequacy or accuracy of this release.
